【 Hot Selling Recommendation 】 Efficient Compression, Easy Enjoyment, Kailifeng Xingchen 14 Square P

The KLF5182ZYSBEV Pure Electric Compression Garbage Truck From Kailifeng Brand Adopts Rear Loading Compression Technology To Complete The Collection And Transportation Of Urban Household Waste, With Significant Advantages Such As Large Loading Capacity, Intelligent Operation, And Environmental Protection And Energy Saving. This Vehicle Is Mainly Suitable For Collecting, Compressing, And Transporting Bucket, Bagged, And Bulk Household Waste From Urban Residents, Communities, And Government Institutions. Its Comprehensive Performance Has Reached The Advanced Level Of Similar Products In China.

List Of Core Advantages

Why Did You Choose It?

Efficient Homework: The Feeding Time For A Single Cycle Is Only 12-25 Seconds, And The Unloading Time Is ≤ 60 Seconds.

Large Capacity Loading: The Total Volume Of The Container Is 14 Cubic Meters, With A Rated Load Capacity Of 6570KG.

Pure Electric Zero Emission: Equipped With A 210.56kWh CATL Battery, Fast Charging Takes Only 2 Hours.

Multi Mode Operation: Supports Three Operation Modes: Manual, Electronic Control, And Remote Control, Which Are Flexible And Convenient.

Low Driving Requirements: B-license Can Be Driven, Reducing The Threshold And Cost Of Employment.

01. Powerful Pure Electric ChassisEfficient Operation Chassis

Chassis Model

HQG1180EVCS1

Battery System

Using High-quality Lithium Iron Phosphate Batteries From CATL, With A Capacity Of 210.56 KWh, High Battery Density, And Safety And Stability.

Drive Motor

Permanent Magnet Synchronous Motor, Rated/peak Power 175kW/265kW, Rated/maximum Speed 8356/13000RPM.

Charging Method

Supports Fast Charging, Can Be Completed In 2 Hours (single Shot), With A Theoretical Endurance Of 230KM.

Highlight Interpretation: Pure Electric Drive Achieves Zero Emissions And Low Noise, With Powerful Motors And Fast Energy Replenishment To Ensure Efficient Operation Of Vehicles Around The Clock, And Operating Costs Far Lower Than Fuel Vehicles.

02. Efficient Installation SystemCompression And Transportation Expert

Box Volume

14 Cubic Meters Of Large Capacity, Made Of High-strength Manganese Steel Plate, With A Four Axis Rolling Machine For One-time Arc Forming, High Sealing Performance, Reliable Structure, And No Leakage.

Compression Technique

Adopting An External Oil Cylinder Structure And Bidirectional Compression Technology, The Compression Ratio Exceeds 1:4, The Garbage Compaction Degree Is High, And The Loading Capacity Is Large.

Diverse Collection Methods

The Tail Can Be Equipped With Various Structures Such As Flip Board, Triangular Bucket, Floor Bucket, Swing Arm, Etc., Suitable For 120L And 240L Standard Barrels, And Can Be Equipped With A 660L Hanging Rack.

Highlight Interpretation: The Combination Of Efficient Compression Technology And Diverse Collection Methods Can Quickly Process Various Types Of Household Waste, Greatly Improving The Efficiency Of Collection And Transportation.

03. Intelligent Control SystemStable, Convenient, And Worry Free

Intelligent Control System

The Electronic Control System Adopts Imported CAN Bus Design, Modular Structure, And Stable Performance.

Multiple Operations

It Has Three Sets Of Operation Modes: Manual, Automatic, And Semi-automatic. It Supports Operation Inside The Cab, At The Front And Rear Of The Box, And Comes With A Remote Control As Standard.

Safety Induction

By Combining Proximity Switches And Oil Pressure Sensing, An Efficient, Stable, And Easy To Maintain Compression Solution Is Achieved.

User-friendly Design

Equipped With Night Lighting, Dual Sewage Tanks, Drainage Pipes, Complete Operation And Maintenance Manuals And Videos.

Highlight Interpretation: The Intelligent Control System Not Only Improves The Convenience And Safety Of Operation, But Also Automatically Adjusts The Compression Force Through Sensors, Reducing Human Influence And Extending The Life Of The Vehicle.

04. Precision And Intelligent Manufacturing TechnologyQuality Remains Fresh Over Time

Top Intelligent Manufacturing

Using CNC Laser Cutting To Ensure Accuracy, And Intelligent Robot Automatic Welding To Ensure Sealing And Reliability.

Advanced Painting

The Upper Part Can Be Equipped With Electrophoretic Technology, And The Structural Components Come Standard With Electrostatic Powder Coating. The Paint Surface Is Bright And Long-lasting, Achieving Worry Free Anti-corrosion And Rust Prevention For Ten Years.

Rigorous Testing

Dedicated Personnel Conduct On-site Testing And Simulate Various Complex Working Environments, Making It The Only Enterprise In China That Conducts Physical Testing Of Compressed Vehicles Before Departure.

Highlight Interpretation: From The Material To The Coating, The Entire Manufacturing Process Integrates Advanced Technology And Strict Quality Control, Ensuring That Every Car Has Excellent Durability And Reliability.
