【 Hot Selling Recommendation 】 Efficient Compression, Powerful Loading, Kailifeng Dongfeng Tianjin 1

The KLF5181ZYSBEV Pure Electric Compression Garbage Truck From Kailifeng Brand Adopts Rear Loading Compression Technology To Complete The Collection And Transportation Of Urban Household Waste, With A Large Loading Capacity And Multiple Bucket (hopper) Mechanisms. Its Comprehensive Performance Reaches The Advanced Level Of Similar Products In China. The Car Is Equipped With An Intelligent Control System That Can Monitor The Vehicle's Status And Garbage Filling Situation In Real Time, Automatically Adjust The Compression Force, Improve Efficiency, And Extend Its Service Life. Its Electric Drive System And Energy Recovery System Achieve Zero Emission Operation And Efficient Energy Utilization, Making It An Ideal Solution For Collecting, Compressing, And Transporting Bucket, Bagged, And Bulk Household Waste From Urban Residents, Communities, And Government Institutions.

List Of Core Advantages

Why Did You Choose It?

Range Ace: The Chassis Has A Range Of 314 Kilometers, Sweeping Range Anxiety And Covering The Entire City.

Capacity King: With A Super Large Capacity Of 15 Cubic Meters And A 1:4 Ultra-high Compression Ratio, The Single Load Capacity Is Doubled.

Performance Benchmark: Fast Feeding (12-25 Seconds), Faster Unloading (≤ 60 Seconds), Smooth Operation Without Waiting.

Intelligent Control: CAN Bus Intelligent Electronic Control, Supporting Three Modes Of Manual/electronic Control/remote Control, Can Be Operated In The Cab, Front And Rear Of The Vehicle.

Top Protection: Equipped With Electrophoresis And Electrostatic Powder Coating On Structural Components, Achieving Top-quality "ten-year Anti-corrosion And Rust Prevention".

01. Brand Battery And ChassisGold Power Is Reliable And Durable

Chassis Model

DFH1180BEV1

Battery System

Equipped With CATL's 210 Degree High-quality Lithium Iron Phosphate Battery, It Provides A Theoretical Range Of 314 Kilometers, Meeting All Day Operation Needs.

Drive Motor

The Permanent Magnet Synchronous Motor Has A Peak Torque Of Up To 1100N. M, Making It More Powerful For Frequent Start Stop And Uphill Storage In Garbage Stations.

Charging Method

Supports Dual Gun Fast Charging, Which Can Be Fully Charged In 40 Minutes, Maximizing Attendance.

Highlight Interpretation: The Golden Partnership Between "Dongfeng" And "Ningde Times" Means That This Car Has A Hardcore Gene Of High Reliability, Strong Power, And Practical Range Since Birth.

02. Powerful Installation SystemCompression Efficiency Benchmark

Box Volume

15 Cubic Meters Of Ultra Large Capacity, Made Of High-strength Manganese Steel Plate, Formed By A Four Axis Rolling Machine In One Arc, With Reliable Structure, Deformation Resistance, Leakage Prevention, And High Sealing Performance.

Compression Technique

Adopting An External Oil Cylinder Structure And Bidirectional Compression Technology, The Compression Ratio Exceeds 1:4, The Garbage Compaction Degree Is Extremely High, And The Loading Capacity Far Exceeds That Of Vehicles Of The Same Volume.

Collection Method

The Tail Can Be Equipped With Various Structures Such As Flip Board, Triangular Bucket, Large Floor Bucket, Swing Arm, Etc., Which Can Easily Adapt To 120L And 240L Standard Barrels, And Can Be Equipped With A 660L Large Hanging Rack.

Highlight Interpretation: The Combination Of Large Capacity And High Compression Ratio Maximizes The Amount Of Garbage Processed In A Single Operation, Effectively Reducing The Number Of Trips To And From Transfer Stations And Significantly Improving Overall Operational Efficiency.

03. Intelligent Control SystemStable, Convenient, And Worry Free

Intelligent Control

The Electronic Control System Adopts Imported CAN Bus Design And Modular Structure, Which Is More Intelligent And Stable Compared To The Old PLC.

Multiple Sensing

By Combining Proximity Switches And Oil Pressure Sensing, An Efficient, Stable, And Easy To Maintain Compression Solution Is Achieved.

Multi Mode Operation

It Has Three Sets Of Operation Modes: Manual, Automatic, And Semi-automatic. It Can Be Operated Inside The Cab, At The Front And Rear Of The Box, And Comes With A Remote Control As Standard.

User-friendly Design

Equipped With Night Lighting, Dual Sewage Tanks, Drainage Pipes, Complete Operation And Maintenance Manuals And Videos.

Highlight Interpretation: Intelligent Control Not Only Reduces The Labor Intensity Of Operators, But Also Reduces The Failure Rate Through Precise Control, Ensuring The Continuity And Reliability Of Operations.

04. Precision And Intelligent Manufacturing TechnologyTen Years Of Worry Free Quality

Top Manufacturing

Using CNC Laser Cutting To Ensure Accuracy, And Intelligent Robot Automatic Welding To Ensure Sealing And Reliability.

Advanced Painting

The Upper Part Can Be Equipped With Electrophoresis, And The Structural Components Come Standard With Electrostatic Powder Coating. The Paint Surface Is Bright And Long-lasting, Achieving Worry Free Anti-corrosion And Rust Prevention For Ten Years. The Structural Components Have High Universality And Are Easier To Maintain In The Later Stage.

Rigorous Testing

Dedicated Personnel Conduct On-site Testing And Simulate Various Complex Working Environments, Making It The Only Enterprise In China That Conducts Physical Testing Of Compressed Vehicles Before Departure.

Highlight Interpretation: From Sheet Metal Cutting To Vehicle Painting, The Entire Manufacturing Process Integrates Advanced Technology And Strict Quality Control, Ensuring That The Vehicle Still Has Long Life And High Reliability In Harsh Environments.
