【 Hot Selling Promotion 】 Kailifeng Heavy Truck HOWO Compressed Garbage Truck

The Strongest And Most Efficient Operation In The Same Class

Heavy Duty Truck Haowo Mighty General Compression Garbage Truck

The Kaili KLF5090ZYSZ6 Compressed Garbage Truck Is Developed Based On The Special Chassis (wheelbase 3280mm) Of The Heavy-duty Truck Howo, And Is Equipped With A Weichai 140 Horsepower National VI Diesel Engine (103kW).

The Effective Volume Of The Box Is 7m ³, And The Rated Load Capacity Is 3370kg, Which Is The Strongest Load Capacity Among 5-8 Cubic Meter Vehicle Models. Standard Configuration Includes Bidirectional Compression Technology And Four Mode Intelligent Control Mode, Designed Specifically For High Load Scenarios Such As County Transfer Stations And Industrial Areas.

Core Configuration

Chassis Parameters

Model: Heavy Duty Truck Haowo Haojiang

Wheelbase: 3280mm

Tire: 7.50 Steel Wire Tire

Power System

Engine: Weichai WP2.30140E62 | 103kW

Horsepower: 140 Horsepower

China VI Emission Standard

Dimensions And Mass

Dimensions: 6610/6655mm × 2160/2050mm × 2670mm

Curb Weight: 5600/5830kg

Rated Mass: 3140/3370kg

Box System

Volume: 7m ³

Unloading Time: ≤ 60 Seconds

Tail Device: Four Types Of Structures Are Available, Including Flip Board, Triangular Bucket, Large Landing Bucket, And Swing Arm Mechanism, To Meet Different Scenarios

Operation Control

Four Mode Operation: Driver's Cab, Multi Way Valve, Rear Electronic Control, Remote Control

Control System: Imported CAN Bus+remote Control

Hydraulic System

New Structure External Oil Cylinder, Rodless Chamber For Oil Intake, Boosting And Speeding Up, Maintenance Free.

One Feed Cycle Time 12-25 Seconds

Compression Ratio ≥ 1:4

Special Design Hydraulic System

1: The Entire Series Comes Standard With A Bucket Lever With Spring Buffering, Which Can Effectively Prevent Damage To The Garbage Bin Caused By Inertia Swinging During Garbage Loading.

2: Thickened Slide, Built-in Nylon Slider, Optimized Slide Structure, Minimal Wear During Use, And Easier Maintenance In The Later Stage.

3: Double Sewage Tank+drainage Pipe+night Lighting Design, With Humanized Details Fully Integrated.

Product Features

Circular Streamline Box Body

The Box Adopts A Circular Arc Flow Linear Shape, Which Is Formed By A Four Axis Plate Rolling Machine In One Rolling Arc, Eliminating The Risk Of Leakage From The Root. The Material Selected Is High-strength Manganese Steel Plate, Which Not Only Has Strong Deformation Resistance And Good Structural Reliability, But Also Is Not Easy To Deform, Wear-resistant, And Corrosion-resistant. At The Same Time, It Effectively Increases The Actual Volume And Exceeds The Loading Capacity Of Similar Products.

Intelligent Electrical System

The Vehicle's Electrical System Can Achieve Fully Automatic Control Of Engine Output, Allowing For Autonomous Selection Of Acceleration Or Idle States During Operation Or Other Working Conditions, Reducing Power Loss And Failure Rates, Lowering Fuel Consumption, And Making Operations More Stable And Energy-efficient.

Multi Mode Intelligent Control

The Intelligent Control System Adopts An Imported CAN Bus Design, Modular Structure, And Combines Proximity Switches And Oil Pressure Sensing Dual Methods To Achieve An Efficient, Stable, And Easy To Maintain Compression Solution. Equipped With Four Sets Of Operation Modes: Manual, Automatic, Semi-automatic, And Remote Control, It Can Be Operated Inside The Cab, In The Front Of The Box, And At The Back Of The Box. It Also Comes Standard With A Remote Control, Which Is Fully Adaptable To Different Working Environments And Easy To Operate Efficiently.

Bidirectional Compression Technology

Adopting The Latest External Oil Cylinder Structure And Bidirectional Compression Technology, Combined With Top Domestic And Foreign Brand Accessories, The Compression Ratio Exceeds 1:4, With A Single Cycle Time Of ≤ 20 Seconds, And The Garbage Collection Efficiency Is Doubled, Making It Easy To Meet The Needs Of Large Amounts Of Garbage Transportation.

User-friendly Design

Fully Considering The Customer's Usage Environment, Thoughtfully Configuring Night Lighting To Facilitate Night Work; Equipped With Dual Sewage Tanks And Drainage Pipes To Prevent Environmental Pollution Caused By Sewage Leakage; Equipped With Complete Operation And Maintenance Manuals And Videos, Making It Easier To Get Started. More Importantly, As The Only Enterprise In China That Conducts Physical Testing Before Compressed Delivery, Kaili Has Dedicated Personnel To Simulate Various Complex Working Environments For Testing, Ensuring Product Reliability.

Product Advantages

Precision Manufacturing Quality Assurance

Using CNC Laser Cutting, The Precision Of The Tooling Is Guaranteed; Intelligent Robot Automatic Welding, Safe And Reliable, With Good Sealing, Ensures Product Quality From The Source.

Top Coating Is Durable And Long-lasting

Choose Top Electrophoresis And Equip With Modular Design And Standardized Production Of Structural Components With Standard Electrostatic Powder Coating. The Paint Surface Is Bright And Durable, Moisture-proof And Corrosion-resistant, And Has A Worry Free Ten-year Anti-corrosion And Rust Prevention, Reducing Maintenance Costs In The Later Stage.

Efficient And Practical, Value For Money

The 7-square Capacity Combined With Bidirectional Compression Technology Leads The Way In Operational Efficiency, Making It A Profitable Tool For Improving The Efficiency Of Garbage Transportation.

Intelligent Control, Stable And Convenient

The Electronic Control System Is Developed In Collaboration With Foreign Technical Teams. Compared To The Old PLC, The CAN Bus Control Is More Intelligent, Paired With A Photoelectric Sensing System And A Standard Remote Control, Providing More Stable Performance And Convenient Use.

Ultra High Repurchase Reputation Certification

With Excellent Quality And Performance, The Product Has A High Repurchase Rate, And Once Used, It Will Not Be Missed. The Customer Stickiness Is High And The Trust Is Strong.

Full Service, Worry Free After-sales Service

The 24-hour After-sales Service Team Is Well-known And Well Received In The Industry, With The Slogan "Kaili Wanli Xing Service Sees True Love" And A 400 Global After-sales Service Hotline. With Fast Response And Worry Free After-sales Service, You Can Use The Car Without Any Worries Throughout The Entire Process.

Industry Recognition For Leading Technology

As A National High-tech Enterprise, A Specialized And Innovative "little Giant" Enterprise In Hubei Province, And A Single Champion In The Manufacturing Industry In Hubei Province, Kaili Group Has Mature Production Processes And Excellent Technical Teams, And Its Product Technical Strength Is Guaranteed.

Full Industry Chain Support, Strong Backing

Kaili Automobile Group Covers The Entire Industry Chain Of Research And Development, Production, Sales, And Service, With Advanced Production Equipment And Production Lines, Providing Strong Support For Product Quality And Service.

This Heavy-duty Truck, The Howo, Is Widely Applicable In Various Scenarios, Including Street Garbage Collection For Municipal Sanitation, Daily Garbage Collection For Residential Properties, Industrial Waste Transportation For Enterprises, Factories, And Construction Sites, Domestic Waste Treatment For Government Institutions, Parks, And Factories, As Well As Garbage Collection And Transportation For Underground Garages, Power Stations, Towns, And Other Scenarios. It Can Easily Meet The Needs Of Garbage Collection And Transportation In Different Environments.

Choosing The 7-party Heavy-duty Truck Haowo Haojiang Compressed Garbage Truck Is Not Only About Choosing A High-performance Environmental Sanitation Equipment, But Also About Choosing A Worry Free, Efficient, And Reliable Garbage Transportation Solution. Kaili Is The Most Responsible Company, Using Strong Products To Easily Achieve Efficient Operations With You!
